How fire spreads — and what stops it.
Fire spreads by conduction, convection and radiation. Smoke moves further and faster than flame, carried by convection through every opening a building leaves open. This page explains each mechanism in plain terms, the routes fire and smoke actually take through a building, and how compartmentation holds a fire in the room where it starts so people have time to get out.
How does fire spread in a building?
Fire spreads by three mechanisms: conduction, heat passing through solid materials; convection, hot gases rising and travelling along ceilings; and radiation, heat crossing open space to ignite what faces it. Inside a building it moves along whatever routes are open: doorways, unsealed service penetrations, and the concealed voids above ceilings and inside walls.
The physics is the same in every fire. What differs, building to building, is the set of routes on offer. A fire in a room with an intact compartment line has almost nowhere to go, and is held long enough for people to leave. The same fire with an unsealed riser above it, or a gap around a pipe through the wall, has a highway. That is why the questions that matter about fire spread are mostly questions about openings, and why the counter-measures are built into the fabric of the building rather than bolted on. The strategy that does it is unpacked in our compartmentation explainer, one of the plain-English explainers in our resources library.
Convection fire: how heat spreads by conduction and radiation
Three mechanisms move heat, and each one defeats a different kind of barrier. Read them once and the routes fire takes through a building stop being mysterious.
Conduction · through solids
Heat travels along the material itself. A metal pipe or beam crossing a wall carries heat to the far side and can ignite what touches it there, while the wall stays intact.
Convection · through air
Hot gases rise, collect at the ceiling and push outwards, then climb through any opening they find. Convection fire spread is the main way fire and smoke move through a building.
Radiation · across space
Heat travels as energy waves, with nothing touching. A hot enough fire ignites surfaces across a gap, driving flame spread between surfaces — and even between buildings — that never touch.
Schematic. Real fire behaviour depends on fuel, ventilation and geometry; the three mechanisms are the constants underneath every case.
How does smoke spread?
Smoke is carried by convection, and it outruns flame. It rises, banks along ceilings, and pushes through every unsealed opening: the gap around a pipe, an open joint at the head of a wall, the void above a suspended ceiling. Vertical shafts are the worst case. A riser with unsealed penetrations works like a chimney, moving smoke to floors far above the fire while the flame itself is still contained. Smoke reaches people long before the flame does, which is why the small, invisible openings matter as much as the doors everyone can see.
- Through unsealed penetrations Every pipe, cable and duct crossing a wall or floor leaves a gap. Unsealed, each one is a smoke route.
- Through concealed voids Above ceilings and inside wall build-ups, smoke moves past intact rooms without anyone seeing it travel.
- Up shafts and risers Stairwells and service risers carry smoke vertically. An unsealed riser behaves like a chimney.
How long does it take for a fire to spread?
There is no single number, and any page that gives one is guessing. The rate of fire propagation depends on what is burning, how much air the fire can reach, and the routes on offer. What can be said with confidence is directional: a fire grows fastest once hot gases bank against the ceiling and radiate heat back down, and every open route — a wedge-open door, an unsealed penetration, an open riser — moves the timeline the wrong way. The purpose of compartmentation is to make the answer irrelevant: hold the fire in the space where it started for a rated period, measured in minutes against a standard test, so the people above and beyond it have time to leave.
How is the spread of fire in buildings stopped?
By closing the routes before the fire exists. That is passive fire protection: built into the fabric of the building, working without being switched on, one measure per route. Each measure only holds if it is installed exactly as tested, which is what firestopping training exists to get right.
Compartmentation
The building is divided into fire-resisting boxes, commonly rated to hold fire for 30, 60 or 120 minutes, so fire and smoke are held in the space where they start. The strategy behind it is explained in what is compartmentation.Firestopping
Every service crossing the compartment line is sealed with a tested system, so the gaps that carry smoke stop existing. The install is firestopping & compartmentation.Cavity barriers
The concealed voids above ceilings and inside walls are closed off, cutting the hidden routes convection uses to move fire past intact rooms.Fire spread, answered
How does fire spread in a building?
By conduction, convection and radiation, along whatever routes the building leaves open: doorways, unsealed service penetrations, gaps around pipes and cables, and the concealed voids above ceilings and inside walls. The routes, not the physics, are the part a building controls.
What is conduction in a fire?
Heat transferred through solid material by direct contact. Heat conducted along a metal pipe, beam or duct can pass through a wall and ignite material on the far side, even though the wall itself never fails. It is one reason a pipe crossing a fire-rated wall needs a tested seal around it.
What is convection in a fire?
The movement of heat in gases. Hot smoke rises, collects at ceiling level, spreads across the floor plate and climbs through any opening it finds: stairwells, risers, unsealed penetrations and ceiling voids. Convection is the main way fire and smoke move through a building.
What is radiation in a fire?
Heat travelling as energy waves across open space, with no contact needed. A fully involved room radiates enough heat to ignite furnishings, or a neighbouring building, across a gap. It is how fire appears to jump between surfaces that never touch.
How does smoke spread?
By convection, through every unsealed opening: service penetrations, gaps around pipes, ceiling voids and shafts. An unsealed riser behaves like a chimney and carries smoke floors above the fire. Smoke moves further and faster than flame, which is why sealing small openings matters so much.
What are the three ways fire can spread?
Conduction, convection and radiation. Conduction moves heat through solids, convection moves it in hot gases, and radiation moves it as energy waves across space. Inside a building, convection through openings and concealed voids is the route that matters most.
